HTR High Temperature Filter Cartridge / HTR High Temperature Pleated Filter Elements
PPS high temperature filter cartridge
PPS high temperature filter material, galvanized metal/stainless steel top and bottom covers,
The unique high temperature resistant structure , the maximum operating temperature of 190℃.
Optional after-treatment: PTFE membrane coated on the surface.
NOMEX high temperature filter cartridge
NOMEX high temperature filter material, galvanized metal/stainless steel top and bottom covers,
The unique high temperature resistant structure , the maximum operating temperature of 232℃.
Optional after-treatment: PTFE membrane coated on the surface.
P84 high temperature filter cartridge
P84 Polyimide fiber filter material, galvanized metal/stainless steel top and bottom covers,
The unique high temperature resistant structure , the continuous operating temperature of 220℃, the maximum operating temperature of 260℃.
Optional after-treatment: PTFE membrane coated on the surface.
Specification
| HTR Model |
Cover Material (Galvanized metal) |
Tube sheet H.D(m²) |
Top cover O.D(m²) |
Bottom cover O.D(m²) |
Filtration area/(m²) | Filtration area/(m²) |
| HD/LH 127 | Galvanized metal | Φ127 | Φ146 | Φ114 | 1.1(m²) | 2.3(m²) |
| HD/LH 133 | Galvanized metal | Φ133 | Φ152 | Φ121 | 1.5(m²) | 3.0(m²) |
| HD/LH 159 | Galvanized metal | Φ159 | Φ178 | Φ144 | 2.1(m²) | 4.1(m²) |
| HD/LH 162 | Galvanized metal | Φ162 | Φ178 | Φ146 | 2.3(m²) | 4.6(m²) |
| Our products have been upgraded with longer cartridges for choice. | ||||||
The length of filter cartridge can be customized according to the customers' working conditions. Please consult HD application technicians about details.
