Wastewater Polypropylene Filter Press Cloth Replacement 600gsm For Slurry Dewatering

Certification
China Zhejiang Huading Net Industry Co.,Ltd certification
I'm Online Chat Now

Wastewater Polypropylene Filter Press Cloth Replacement 600gsm For Slurry Dewatering

Wastewater Polypropylene Filter Press Cloth Replacement 600gsm For Slurry Dewatering
Wastewater Polypropylene Filter Press Cloth Replacement 600gsm For Slurry Dewatering Wastewater Polypropylene Filter Press Cloth Replacement 600gsm For Slurry Dewatering

Large Image :  Wastewater Polypropylene Filter Press Cloth Replacement 600gsm For Slurry Dewatering

Product Details:
Place of Origin: CN
Brand Name: HD
Certification: ISO9001:2015
Payment & Shipping Terms:
Minimum Order Quantity: 50 Pieces
Price: Negotiable
Packaging Details: Polybag
Delivery Time: 10-15 Work Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 Pieces per Month

Wastewater Polypropylene Filter Press Cloth Replacement 600gsm For Slurry Dewatering

Description
Material: Polyester / Polypropylene / Polyamide /Vinylon Filter Type: Press Filter
Size: OEM Application: Mining, Slurry Dewatering, Coal Washing, Alumina
High Light:

Filter Press Cloth Replacement Slurry Dewatering

,

Wastewater Filter Press Cloth Replacement

,

Polypropylene Filter Cloth 600gsm

Mining Industry Filter Press Cloth Dry Cake Filtration



HD Filter Cloth Liquid Solid Separation Filter Cloth is mainly applied for Mining industry, Chemical Industry, Food industry. Mineral tailing concentration, Wastewater treatment, sludge sewage dewatering, kaolin clay, quarry, granite production process etc.



HD Filter Cloth Liquid Solid Separation Filter Cloth is mainly applied for Mining industry, Chemical Industry, Food industry. Mineral tailing concentration, Wastewater treatment, sludge sewage dewatering, kaolin clay, quarry, granite production process etc.



Filter press is increasingly applied by more and more industries such as Metallurgy, Mining, Printing as an effective and affordable equipment of solid-liquid separation. As an essential factor of filter press, filter cloth plays an important role to ensure clear filtration, dry filter cake and short filter cycle.

Wastewater Polypropylene Filter Press Cloth Replacement 600gsm For Slurry Dewatering 0



Filter cloth selection mainly depends on

1). Materials.

2). Yarn Types.

3). Weave Patterns.



Materials:

Polypropylene Filter fabric:

Polypropylene Filter fabric is characterized by sleekness, excellent permeability and nil moisture absorption. Its excellent cake release will significantly shorten cleaning time as well as filter cycle. It also has excellent resistances against most acids and alkalis. Its constant working temperature is rated at 280 °F.

Nylon filter cloth:

Nylon filter cloth features optimum abrasive resistance and strong alkali resistance. It is often found in miner and coal industries for its best abrasion proof. The only shortage is that its chemical instability under high temperature when it will release toxic substance and pollute the solutions. So, nylon filter cloth is not accepted by food & beverage and pharmaceutical.

Polyester (PE) filter cloth:

The prominent property for polyester fabric is its strongest acid resistance among existing synthetic fabrics. It is widely recognized as an outstanding and popular filter cloth for its high operating temperature up to 302 °F, high tensile strength and good elongation.

Vinylon filter cloth:

Thanks to its strongest alkali resistance, vinylon filter cloth is suitable for caustic condition. Its working temperature is less than 140 °F.



Properties of Frequently Used Filter Fabrics
Property Polyester (PE) Polypropylene Vinylon
Acid Excellent Excellent Poor
Alkali Average Excellent Excellent
Electrical Conductivity Poor Good Average
Elongation 30%-40% Better than PE 12%-25%
Recovery Excellent Slightly better than PE Poor
Abrasion Excellent Good Excellent
Heat Resistance 170 °C 90 °C 100 °C
Softening point 230 -240 °C 140 -150 °C 200 °C
Melting point 255 -265 °C 165 -170 °C 220 °C



HD Filter Cloth:

Filter Cloth For plate filter press , Belt Filter Press , Disc Filter , etc.
1). Filter Cloth : Polyester Filter Cloth , Polypropylene Filter Cloth , PA Filter Cloth ,
2). Weight standard: 250g / sqm - 900 g / sqm . Make to order is also accepted.
3). Polyester Monofilament Filter Cloth are widely applid in sugar plant and iron ore industry filter press .

4). Non woven felt filter cloth, 600- 800 gsm weight.

Filter Cloth Material:
Polyester(Terylene/PET) Filter Cloth
Polypropylene (PP) Filter Cloth
Chinlon (polyamide/nylon) Filter Cloth
Vinylon PV Filter Cloth

Needle felt

Cotton

Filter Cloth Application:


Mining Industry: Coal Washing , Tailing of Gold / Zinc / Nickle, Tialing of coal, Kaolin clay, Cement, Aggregate, Asphalt, etc.

Environmental protection: Sewage treatment, Sludge dewatering, flue gas desulphurization, Salt mud, fly ash, etc.

Chemical Industry: Pigment, Zinc oxide, Activated carbon, Iron oxide, Nickle, Titanium Oxide, White Carbon Black, Calcium Carbonate, etc.

Steel & Iron, Metallurgical Industry: Alumina / Aluminum oxide, Iron Ore, Gold, Leads, Vanadium, Nickel, Zinc, Copper, Titanium etc.

Wastewater Polypropylene Filter Press Cloth Replacement 600gsm For Slurry Dewatering 1

Advantage OF HD Filter Press Cloth:


High dimensional stability
Good abrasion performance
Wide range of filter rate
Efficient fabric cleaning
Smooth Surface
Easy Cake Releasing
