PTFE Dipping Polyester Needle Felt Anti-Static Heat Setting Felt Filter Cloth

PTFE Dipping Polyester Needle Felt Anti-Static Heat Setting Felt Filter Cloth
PTFE Dipping Polyester Needle Felt Anti-Static Heat Setting Felt Filter Cloth PTFE Dipping Polyester Needle Felt Anti-Static Heat Setting Felt Filter Cloth

Large Image :  PTFE Dipping Polyester Needle Felt Anti-Static Heat Setting Felt Filter Cloth

Product Details:
Place of Origin: CN
Brand Name: HUADING
Certification: ISO9001:2015
Model Number: HD-PENF
Payment & Shipping Terms:
Minimum Order Quantity: 100 Square meter
Price: Negotiable
Packaging Details: Polybag
Delivery Time: 10-15 Work Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500000 Square meter per Month

PTFE Dipping Polyester Needle Felt Anti-Static Heat Setting Felt Filter Cloth

Description
Material: Polyester Technology: Nonwoven
Weight: 300gsm - 800gsm Width: Max 150cm
Finish Treatment: Heat Setting; Singeing; Calendering; Water&Oil Repellent; PTFE Dipping; PTFE Membrane Length: 100m/roll; 50m/roll
Application Industry: Cement Plant; Steel Plant; Chemical Plant
High Light:

PTFE dipping Polyester Needle Felt

,

Polyester Needle Felt anti-static

,

Heat setting Felt Filter Cloth

Polyester Industrial Filter Cloth Felt For Dust Collector Filter PocketPTFE Dipping Polyester Needle Felt Anti-Static Heat Setting Felt Filter Cloth 0



What is Polyester needle felt filter fabrics?



Polyester needle felt is the most widely used filter fabrics for normal temperature dust removal, thanks to its versatile property and high cost-effectiveness. Huading’s Polyester needle felt filter fabrics is made out by long fiber scrim, and fine fiber punching on the surface, in suitable density and thickness to ensure the optimal filtration efficiency and tensile strength.
Various after treatment include water and oil resistance, anti-static, PTFE membrane, etc to meet your different working conditions.



Advantage of Polyester needle felt filter fabrics


1. Good tensile strength
2. Excellent resistance to acid
3. Excellent resistance to solvent
4. Economical
5. Continuous working temperature <135℃, surge 150℃



Disadvantage of Polyester needle felt filter fabrics


Polyester is easy to hydrolysis in high temperature and high humidity working conditions, there is ester group on the polyester macromolecular chain, which is easy to rift in the tough high-temperature and high-humidity conditions, this causes the degradation of the filter material and reduces the service life.



Application of Polyester Needle Felt Filter Fabrics



1. Mining
2. Cement industry
3. Metal industry
4. Aluminum and non-ferrous metal industry
5. Ceramic industry
6. Quarrying
7. Plastic
8. Milk powder
9. Flour mill (used under dry conditions up to 150°C)

PTFE Dipping Polyester Needle Felt Anti-Static Heat Setting Felt Filter Cloth 1



Properties



Composition PE/anti-static scrim
Weight (g/m2) 500
Thickness (mm) 1.80
Air permeability (L/m2/s) 200-350
Tensile strength (N/5×20cm) Warp 1000
Weft 1250
Tensile elongation (%) Warp <35
Weft <55
Broken strength (Mpa/min) 2.40
Working temperature(℃) 130
Short time working temperature (℃) 150
Anti-acid Fair
Anti-alkali Fair
Anti-abrasion Excellent
The stability of water solution Fair
Finishing treatment Singeing, calendaring

Specification

Para Weight (g/sm) Thickness (mm) Air Permeability (cbm/sm/min) Tensile Strength

(N/5×20cm)

Tensile Elongation

(%)

Operating Temp.

(°C/℉)

Max Surge Temp.

(°C/℉)

Suitable P.H. Value
Model / / / Warp Weft Warp Weft / / /
PE-01 530 3.5 10 1000 1800 50 50

90/194

Dry Heat

150/302

Dry Heat

4-12
PE-05 530 2.5 22 800 1000 60 60 4-12
PE-10 480 2.2 24 800 1000 60 70 4-12
PE-25 480 2.8 35 500 800 70 70 4-12
PE-50 430 3.5 70 500 600 100 80 4-12
PE-75 430 3.5 80 500 600 100 80 4-12
PE-100 380 3.5 100 500 500 100 100 4-12
PE-200 380 3.8 100 500 600 110 100 4-12
